FULL WALL EFFECTIVE THERMAL PERFORMANCE
Climate Zone 7B
Above-Grade Wall 2.8
Cathedral Ceiling/ Flat Ceiling 5.02
Effective R-Value for Split Insulated Steel Stud Assembly with Horizontal Rails R-18.6 (3.27)
Effective R-Value for Split Insulated Steel Stud Assembly with Vertical Rails: R-18.0 (3.17)
Effective R-Value for Exterior Insulated Steel Stud Assembly with Horizontal Rails: R-10.2 (1.80)
Effective R-Value for Exterior Insulated Steel Stud Assembly with Vertical Rails: R-10.0 (1.77)
WALL STRUCTURAL CAPACITY
Max. Wind Load 20 [psf]
Horizontal Spacing: 24 [in]
Vertical Spacing: 42 [in]

Area
Area in² 10000 [in²]
Number Of Clips: 10
Result
Contact Us
Structural Capacity - Maximum Allowable Wind Load [psf]

= Wind loads highlighted in blue require two power keys

  Max Wind Load [PSF]
hv \ hh (in) 16 24 32
24 61 39 28
30 48 30 22
36 39 24 17
42 33 20 14
48 28 17 12
For more information and spacing options , please contact the EJOT CROSSFIX team by email at infoCA@ejot.com
Result
EFFFECTIVE THERMAL PERFORMANCE OF WALL ASSEMBLIES [R-VALUEEFF]
